7 Jun 2013

A selection of the best technical images from the Montreal GP during the build phase on Thursday courtesy of Sutton Images




Lotus E21 - Notice the exposed DRS actuator


 McLaren MP4-28 Older config Front Wing from behind







 Mercedes W04 - Note the DRS actuator is exposed


 Sauber C32 - Rear End detail

 Force India VJM06 Floor detail

6


 Williams FW35 - Return of the Boomerang Rear Wing

Toro Rosso STR8 - New Low Downforce configuration Rear Wing




 Marussia MR-02 Exhaust and Rear End detail






 Sauber C32 - Front Wing / Nose - New configuration (top) has a 'Pelican' underbelly and the FOM camera's moved rearward out of the Hammerhead position

 Mercedes W04 - Engine Cover with Shark Fin (Dimensional purposes)




















 Ferrari F138 - New Pylons (Triangular section has been lengthened) these were shown in Monaco but not run




Lotus E21 - New Nose, notice the absence of the 'Pelican' underbelly
